Collier Township Community Park
Collier Township Community Park
LSSE provided engineering and permitting services to the Township of Collier for the $8.5 million phased development of the Collier Community Park. The property is located on the former Charles E. Kelly Support Facility. Ten structures at the former Support Facility were demolished in Spring 2012 in preparation for construction.
Phase I of the project included basketball, tennis and pickleball courts, a Deck hockey rink, multi-purpose fields, playgrounds and picnic areas. Phase II involved a Community Center which included renovation of an existing 25,000-square foot building to function as a community center, and a new attached 10,670-square foot gymnasium.
MARKETS:
- Municipal
SERVICES:
- Landscape Architecture and Planning
